Detail Produk
FEATURES :
UV lamp
Emission of 253.7 nanometers for most efficient decontamination
LCD Display
AirFlow Velocity, UV Timer, UV Work Time
System work time, Real Time
Waterproof Socket
2 Waterproof sockets are located in the side panel,
for optimum convenience of using small devices inside the cabinet
GAS TAP
Side Glass Window
The Transparent side glass windows maximize light and
Visibility Inside the cabinet, providing a bright and open working environment
TYPE : BBS-V680; BBSV-800; BBS-DDC; BBS-SDC
Model | BBS-V680 | BBS-V800 | BBS-DDC | BBS-SDC |
External Size (W*D*H) | 680*410*1160 mm | 802*650*1550 mm | 1040*615*1770 mm | 1440*615*1770 mm |
Internal Size (W*D*H) | 630*375*675 mm | 800*530*540 mm | 940*540*545 mm | 1340*540*545 mm |
Work Surface Height | / | 660 mm | 750 mm | 750 mm |
Display | LED Display | |||
Airflow Velocity | Average of 0,30 – 0,50 m/s ; air speed adjustable | |||
Material | Main Body : Cold Rolled steel with anti-bacteria powder coating | |||
Work table : 304 Stainless Steel | ||||
Pre-Filter | Polyester fiber; Washable | |||
HEPA Filter | 99,999% efficiency at 0,3µm | |||
Noise | ≤65 dB(A) | |||
Front Window | / | manual | ||
5 mm toughened glass, anti-UV | ||||
Iluminating Lamp | Fluorescent Lamp | LED Lamp | LED Lamp | LED Lamp |
14W*1 | 8W*1 | 12W*1 | 16W*1 | |
UV Lamp | 15W*1 | 20W*1 | 18W*1 | 30W*1 |
Emission of 253,7 nanometers | ||||
Consumption | 160W | 350W | 350W | 600W |
Caster | / | Universal Caster with leveling feet | ||
Power Suply | AC220±10%; 50/60 Hz; 110V±10%; 60 Hz | |||
Standard Accessory | Fluorecent Lamp | LED Lamp | ||
UV lamp*2 | UV lamp*2 | |||
Water & Gas Tap | Base Stand | |||
Optional Accessory | / | Electric Height adjustable base stand | ||
Gross Weight | 50 kg | 160 kg | 131 kg | 174 kg |
Package Size | 840*560*1380 mm | 960*800*1800 mm | 1200*850*1360 mm | 1600*850*1360 mm |
